Call 1-800-623-2580Thin-8FB 8ʺ Thin Amber Flashing Beacon
Product
Single Flashing Beacon, amber, yellow background, 30 W solar power unit
Product number
37737
Dimensions
18 x 28 x 14 in – 21 lbs
Price
1702$
Product
Dual Flashing Beacon, amber, yellow background, 30 W solar power unitt
Product number
37738
Dimensions
18 x 32 x 14 in – 32 lbs
Price
2150$
Fast shipping
Need a quote for a large order?
Call 1-866-623-2580 or send us an email
REINFORCES THE SIGN IN CRITICAL ZONES
SOLAR POWER SUPPLY
INCREASES ROAD USERS’ SAFETY
LOW INSTALLATION COSTS
FEATURES OF THE 8ʺ THIN AMBER FLASHING BEACON
Aluminum
Light and resistant. Installs like a standard traffic sign.
Powerful LED
Integrated into the sign and protected by polycarbonate lens.
Controller
Photocell, flashing patterns, wireless communication and scheduled activation.
Reflective
High intensity yellow sheeting or black background.
Snap-in Connector
Small enough to be hidden inside pole.
IP 67 protection.
SOLAR POWER UNIT (ALL-IN-ONE & PLUG-AND-PLAY)
Monocrystalline Cells
Higher-efficiency solar panel to optimize size.
LifePo4 lithium Battery
Light and slim. 10-year life expectancy. Maintenance free.
MPPT Charger
Increases charging efficiency by at least 20% compared to PWM.
Universal Mounting Bracket
Top or side of pole installation.
LED Status Indicator
Snap-in Connector
TECHNICAL SPECIFICATIONS OF THE 8ʺ THIN AMBER FLASHING BEACON
Solar Power Unit (All-in-one)
Monocrystalline Solar Panel: 30 W
LifePo4 Battery: 12.8 V – 14 Ah
Solar Charger: MPPT, 10 A, IP67
Connector: 10 mm OD, Male, 6ʺ, IP67
Operating Temperature: -40 to +74°C (-40 to +165°F)
Weight: 7.7 kg (17 lb)
Flashing Beacon
Beacon size: 200 mm (8ʺ)
Standard: ITE VTCSH-STD 2005, EN 12352 L8M Class
Color: Amber 590 nm
Life Expectancy: 100,000 hours
Luminous Intensity: 650 cd day – 200 cd night
Auto-dimming: Variable based on ambient light
Voltage In: 10.8 to 15 VDC
Max Power @ 12 V: 8 W
Wireless Communication: Encrypted 902 MHz, up to 100 m (300ʹ)
Connector: 10 mm OD, Male, 6ʺ, IP67
Flash Patterns: 0.1 – 0.2 – 0.5 sec, tri-flash or WW+S
Flash Rate: 60 per minute
Activation: 24/7, night only, calendar, on-demand
Default Setting: 0.1 sec, 24/7
Back Plate: Aluminum 5052-H38, 2 mm (.08ʺ)
Sheeting (Black): 3MTM ScotchcalTM
Reflective Sheeting (Yellow): 3MTM Prismatic High intensity Type IV
Visor: Aluminum, black painted textured (yellow exterior also offered)
Lens: UV-resistant transparent polycarbonate
Waterproof Rating: IP65
Operating Temperature: -40 to +50°C (-40 to +131°F)
Weight: 1.4 kg (3 lb)
| Product Number | Description | Box : Dimenson – Weight | HSS Code | |
|---|---|---|---|---|
| #37737 | Single Flashing Beacon, amber, yellow background, 30 W solar power unit | 18 x 28 x 14 in – 21 lbs | 8530.90 | Buy This Assembly |
| #37738 | Dual Flashing Beacon, amber, yellow background, 30 W solar power unit | 18 x 32 x 14 in – 32 lbs | 8530.90 | Buy This Assembly |
included in kit: Installation hardware for 2’’ Telespar post, 2-3/8‘’ round pole, U-Post or streetlight pole. Two (2) years Limited Warranty against defects in workmanship and materials.
